AA-SM-001-000 Section Properties of Common Cross Sections

Free Engineering Spreadsheets: Section Properties of Common Cross Sections. Note that the spreadsheet cells with blue ink are the input values - all other cells are either text or values generated by the spreadsheet

AA-SM-001-000




11 August 2016 - Rev B - Multiple improvements, reorganization to include first moment of area and now includes the shape factor of various sections for cozzone plastic bending analysis

13 September 2016 - Rev C - Corrected several expressions for first moment of area, added more calculations and corrections for plastic bending shape factors

15 September 2016 - Rev D - Corrected first moment of area for rectangle (Thanks to 'Stress Team')

31 January 2017 - Ref F - Corrected for distance to outer fiber for rectangle
